Tugger Carts - Quad Steer

Only %1 left

SKU

TT-QS

Quad Steer Tugger Carts (TT-QS) provide safe and efficient material handling alone or in logistics trains. Quad Steer models are the most maneuverable models available for picking trains and milk-run systems. Both axles steer in tandem to improve the turning radius along the entire train, with precise tracking fidelity.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Overview

Quad Steer Tugger Carts (TT-QS) provide safe and efficient material handling alone or in logistics trains. They can be pulled by virtually any tugger, including automated guided vehicles (AGV.) Operators can pull high-capacity pick trains comprised of multiple TT-QS units, which secure to one another with universal tow bars and hitches.

The quad-steer mechanism creates clean, reliable tracking, improving safety for tugger operators. These trailers create a predictable follow pattern behind tuggers, which frees operators to keep their attention on the path ahead. Quad-steer models can navigate tight corners and even U-turns easily.

Heavy-duty steel construction gives these units high load capacities, while a damage-resistant powder coating ensures long, dependable service life. To learn more about Quad Steer Warehouse Trailers, or to find a dealer near you, call BHS at 1.800.BHS.9500.

Features & Benefits

Reduces order picking time by creating a pick train
Safe, efficient material handling for manufacturing and warehousing applications
Quad steering provides precise tracking fidelity and a tight turn radius
2,000 lb capacity models available
Heavy-duty 6″ x 2″ polyurethane-on-steel casters
Standard units include ring coupler and clevis hitch
Custom hitches available on request
Travels in line behind tuggers for easier navigation
Configurable to support any materials
Compatible with all types of electric tuggers
Custom builds available on request

Specifications

MODEL	WIDTH	LENGTH	DECK HEIGHT*	CAPACITY	WEIGHT
TT-QS-3660	36” / 914 mm	60” / 1524 mm	8.5” / 216 mm	2,000 lb / 907 kg	300 lb / 136 kg
TT-QS-3672	36” / 914 mm	72” / 1829 mm	8.5” / 216 mm	2,000 lb / 907 kg	325 lb / 147 kg
TT-QS-4896	48” / 1219 mm	96” / 2438 mm	8.5” / 216 mm	2,000 lb / 907 kg	550 lb / 250 kg
TT-QS-5050	50” / 1270 mm	50” / 1270 mm	8.5” / 216 mm	2,000 lb / 907 kg	325 lb / 147 kg

*Varies based on casters selected

Options

HITCH / TOW BAR

HD Pintle Hitch & Pintle Ring (TT-PH): Heavy-duty, rigid pintle-style hitch; ideal for rough terrain
Ball Coupler & Ball Hitch (TT-BALL): Clamp-style attachment features a tight fit for smooth transport

TRANSPORT

8” Casters (TT-C-8X2): 8” x 2” easy-rolling polyurethane casters
8” Max Efficiency Casters (TT-C-8X2-ME): 8” x 2” easy-rolling, noise-reducing polyurethane casters
Floor Lock (TT-FL): Parking brake prevents movement of the cart

SHELVING

Shelf (TT-2TIER): Add 1 bolt-on shelf with a 500 lb capacity
Adjustable Shelf (TT-2TIER-ADJ): Add 1 adjustable shelf with a 500 lb capacity
Shelves (TT-3TIER): Add 2 bolt-on shelves, each with a 500 lb capacity
Adjustable Shelves (TT-3TIER-ADJ): Add 2 adjustable shelves, each with a 500 lb capacity
Angled Shelves (TT-AS): Shelves slope downward 2° to the center to aid in retention of load
No Lip (TT-NO): Deck and shelves will not have a lipped edge
