Dual Transfer Carriage
SKU
DTC-16
Converts an existing pallet jack into an portable forklift battery changer with three 16" battery compartments.
The BHS Dual Transfer Carriage (DTC) converts an existing pallet truck into an efficient, portable battery changer. A hydraulic-powered extractor arm makes the change-out process quick and ergonomic, saving your staff time and energy.
The DTC is equipped with three battery compartments which allow two battery change-outs anywhere in your facility. The carriage's combination of lead rollers and friction strips provides increased battery stability while transporting batteries to and from charging stations. A durable powder-coat finish helps the DTC resist acid and scratches in harsh warehouse conditions.
The DTC mounts easily to any powered pallet truck with forks that are 60 inches or longer. A dual SB-175 gray connector harness plugs into the pallet truck and battery, which powers the Dual Transfer Carriage and pallet truck simultaneously.
The pass-through design of the Dual Transfer Carriage conveniently allows battery exchange to and from stands on either side of the unit. Lift truck servicing can be accomplished from the right side of the DTC (arm reach side is from pallet truck operator’s perspective).
Turn your pallet truck into a mobile, industrial battery extractor with the Dual Transfer Carriage. Contact our sales team at 1.800.BHS.9500 to learn more about Battery Carts & Carriages or to locate a dealer.
Features & Benefits
- Three 16” (406 mm) wide battery compartments
- Hydraulic-powered with multi-axis extractor arm
- Magnet extraction ideal for use with narrow batteries
- Pivoting magnet allows magnet to be attached to either side of the battery for extracting and replacing batteries from either side of the unit
- Combination of lead rollers and friction strips provides increased battery stability during transport
- Lowers system cost by utilizing existing equipment
- Mounts easily to powered pallet truck with 60” (1524 mm) or longer forks
- Pendant control for ease of operation
- Dual SB-175 gray connector harness plugs into the pallet truck and battery, powering the DTC and pallet truck simultaneously
- Load and unload batteries to stands on either side of the unit
- Durable powder coat finish resists both acid and scratches
|
DTC-16 |
|
|
Max Load Capacity* |
6,000 lb / 2721 kg |
|
Service Weight (unloaded) |
1,300 lb / 590 kg |
|
Overall Dimensions (L x W x H) |
64.75” x 63” x 65” / 1645 mm x 1600 mm x 1651 mm |
|
Arm Reach (Right Hand Side)† |
15.75” / 400 mm |
|
Arm Reach (Left Hand Side)† |
6.25” / 159 mm |
|
Operating Voltage |
24 V dc |
|
Hydraulic Pump Type |
Gear, Fixed Displacement |
|
Hydraulic Pump Displacement |
3.0 gal/min / 11.4 L/min |
|
Extractor Arm Travel Speed |
18 ft/min / 0.09 m/s |
|
Magnet Carrier Traverse Speed |
18 ft/min / 0.09 m/s |
|
Magnet Size |
4” x 12” / 101 mm x 305 mm |
|
Magnet Draw Bar Pull‡ |
1,000 lb / 453 kg |
|
Roller Diameter |
2.4” / 61 mm |
|
Roller Shaft Size |
0.75” / 19 mm Hex |
|
Battery Compartment Width |
16” / 406 mm |
|
Max. Battery Dimensions (L x W x H) |
40” x 15” x 33” / 1016 mm x 381 mm x 838 mm |
|
Min. Battery Dimensions (L x W x H) |
20” x 6” x 18” / 508 mm x 152 mm x 457 mm |
|
Min. Service Height (Resting on ground) |
6.5” / 165 mm |
|
Min. Pallet Truck Fork Size |
27” x 60” / 686 mm x 1524 mm |
* Max load capacity based on 8,000 lb / 3628 kg host truck.
† Arm reach side is from pallet truck operator’s perspective.
‡ Varies with battery case condition and thickness.
