Dockmaster Hydraulic Bin Dumper, 27.5" tip height
SKU
DM0700
Designed with a specific task in mind, dumping bins from a raised dock, the Dockmaster inverts bins as low to the ground as possible, at just 27.5 inches (700 millimeters), while still keeping the weight within the footprint of the machine.
The Dockmaster Bin Dumper was designed with a specific task in mind - safely dumping wheeled bins and drums from a raised loading dock. In many operations this is currently done by hand, which is difficult, slow and dangerous. The Dockmaster completes the process in seconds and is fully compliant with stringent new safety requirements.
The Dockmaster is based on the proven design of the Dumpmaster, but with unique features. The dumping mechanism inverts bins as low to the ground as possible, at just 27.5 inches (700 millimeters)*, while still keeping the weight within the footprint of the machine. To allow operating near platform edges, the Dockmaster is fitted with safety feet, just behind the wheels. These catch the machine if it is rolled over the edge, instantly preventing further movement.
The Dockmaster is built to the same rugged specifications as the Dumpmaster, including the steel frame, powerpack and control system. It will effortlessly tip most types of two-wheeled bins at weights up to 550 pounds (250 kilograms), and is designed to withstand many years of operation indoors or outdoors.
Contact our sales team at 1.800.BHS.9500 to learn more about the Dockmaster or to locate a dealer near you. Improve staff productivity with an ergonomic Bin Dumper from BHS.
* Tip height is approximate as it varies by bin being dumped.
Features & Benefits:
- Hydraulic powered
- 550 lb (250 kg) lifting capacity
- Ultra-low 27.5” (700 mm) tipping height
- Typical Duty Cycle: 22,000 lb (1000 kg) of material per charge or 11,000 lb (5000 kg) per hour on continuous charge
- Available with battery, solar, 3-phase or compressed-air power supply; battery-powered dumpers have a sealed battery and an industrial-quality ‘float’ charger built in
- Specifically designed for safe operation on raised loading docks or platforms
- Safety bars prevent machine from being rolled over the edge of the dock or platform
- Standard cradles allow dumping all common two-wheeled bins from 24-96 gal (90-360 L) with no clamping or restraint required
- 4” (100 mm) casters for easy movement; two with brakes
- Hot-dip galvanized steel frame and cradle with zinc-plated wire mesh guarding
- Weather-tight control panel with key switch and digital battery indicator/li>
- Small floor footprint
- Automatic interlock safety door
- Virtually maintenance-free, with extremely reliable electro-hydraulic mechanism
- Indoor or outdoor use
| MODEL | TIP HEIGHT | CAPACITY | POWER SOURCE * | OVERALL LENGTH | OVERALL WIDTH | OVERALL HEIGHT | WEIGHT | IP RATING | SAFETY RATING |
|---|---|---|---|---|---|---|---|---|---|
|
DM0700 |
27.5" |
550 lb * |
Battery † 3-Phase ‡ |
46” |
38” |
69” |
≈ 353 lb |
IP56 * |
CAT11/PLc |
|
* Upgradable Specification † Battery powerpack, 24V/20Ah GEL (3hr charge on 100-264VAC 1-ph 50/60Hz ≤ 3A); unit includes sealed battery and industrial quality ‘float’ charger ‡ 3-Phase Mains powerpack, ≈ 415VAC 3-ph 50/60Hz ≤3.6A |
|||||||||
